Description

Highlights

  • flexible use due to low weight
  • small space requirement
  • foldable drill-chuck cover made of acrylic glass
  • solid base plate for good stability
  • max drilling capacity 13 mm
  • practical three armbar with drill depth scaling
  • drill depth stop

  • Technical details

    motor data
    motor power s1 in W 400 W (S2 15min)
    voltage 230V / 50Hz
    measurements
    outreach in mm 104
    total dimensions in mm 420x225x597
    technical specification
    max. drilling performance in mm 1.5-13mm
    drilling spindle speed in min-1 (9) 420-2700
    max. distance spindle-table in mm 220
    distance spindle-base in mm 302
    spindle stroke in mm 50
    base in mm 295×190
    volume level and vibration
    sound power level in dB(A) 82
    sound pressure level in dB(A) 69
    weight
    gross weight in kg 13
    net weight in kg 11
    packaging
    packaging width in mm 386
    packaging length in mm 454
    packaging height in mm 245
    general data
    EAN code 9120039233550
