SIP HG3000S MIG Inverter Welder with SWF 05777

SIP HG3000S MIG Inverter Welder with SWF 05777

1,999.00 incl. Vat

The SIP HG3000S MIG Inverter Welder with Separate Wire Feed is an industrial-grade unit perfect for a wide array of applications in trade, professional and industry environments, utilising heavy-duty components ideal for demanding performance.

— OR  —

— OR  —

EAN: 5012713057771 MPN: 05777 SKU: X0090 Categories: ,

Description

KEY FEATURES

  • Integrated control panel with high-quality digital display
  • Separate wire feed mounted on top of the main welder body
  • Infinitely variable power output settings for versatility
  • Comes with interconnecting harness, torch and accessories
  • Heavy-duty all-metal 4-roll wire feed mechanism

Technical Information

ITEM NO. 05777
Input Supply: 230v (43A)
Output Current: 50A – 250A (MIG)
30A – 200A (ARC)
Output Voltage: 16.5v – 26.5v (MIG)
21.2v – 28v (ARC)
Voltage Steps: Infinitely variable
Duty Cycle: 250A @ 60% (MIG)
200A @ 60% (ARC)
Electrode Diameter: Ø 1.6mm – 6mm
Wire Diameter: Ø 0.8mm – 1mm
Wire Spool Size: 5kg – 15kg
Protection Level: IP21S
Insulation Class: Class H
Net Weight: 48.10kg
Gross Weight: 60.30kg
Product Dimensions:
Packaged Dimensions: 940(H) x 945(W) x 495mm(D)
500(H) x 340(W) x 710mm(D)

Additional information

Weight 60 kg
Dimensions 120 × 128 × 144 cm
Brand

SIP Industrial
