The Weldmate HG 2001DA 200amp Inverter Welder is branded by SIP, one of the leading manufacturers of welders in Europe. SIP have been selling welders for over 40 years. Features an anti-stick circuitry for an easy arc strike.
The Weldmate HG2001DA 200amp Inverter Welder is branded by SIP, one of the leading manufacturers of welders in Europe. SIP have been selling welders for over 40 years. Features an anti-stick circuitry for an easy arc strike.
This Inverter Welder has a high duty cycle of 200amps @ 15%. Comes with a 3M cable, electrode holder and earth lead. Runs from a 16amp plug and the current output range is 20 – 200amps. Very lightweight and portable welder at 7.3 kgs. Ideal for on the go jobs and at 200amps, it still keeps it’s professional edge.
Technical Description:
ITEM NO.
05715
Input Supply
230v (20A)
Output Current
20A – 200A
Peak Current
200A
Duty Cycle
100A @ 60% 200A @15%
Electrode ∅
1.6mm – 5mm
Weld Thickness
1.5mm – 9mm
Open Voltage
69v
Power Factor
0.75
Efficiency
85%
Insulation
Class H
Protection
IP21S
Net Weight
6.50kg
Gross Weight
8.90kg
Additional information
Weight
10 kg
Dimensions
24 × 45 × 34 cm
Brand
SIP Industrial
One response to “SIP HG2001DA 200amp Inverter Welder 05715”
I dont think you can get this HG2000A 200amp anymore. It has been replaced by a HD2001A 200amp which is almost the same but it only has a duty cycle of 6mins at 200amp whereas the HG2000A had a duty cycle of 20mins at 200amp. If your looking for a good inverter welder with a duty cycle of 20mins at 200amp then you need the HG2600A 260amp. So dont get led astray by the HD2001A being a direct replacement for the HG2000A because it isnt.
I dont think you can get this HG2000A 200amp anymore. It has been replaced by a HD2001A 200amp which is almost the same but it only has a duty cycle of 6mins at 200amp whereas the HG2000A had a duty cycle of 20mins at 200amp. If your looking for a good inverter welder with a duty cycle of 20mins at 200amp then you need the HG2600A 260amp. So dont get led astray by the HD2001A being a direct replacement for the HG2000A because it isnt.
