Holzmann BF20V 230V Milling Machine MT2

Holzmann BF20V 230V Milling Machine MT2

Black Friday Sale 2024 Sale Price
Expires December 9, 2024 5:00 pm

Original price was: €1,999.00.Current price is: €1,899.05. incl. Vat

Highlights

  • variable speed control with DRO
  • DRO for drill depth indication as standard
  • CW and CCW run
  • dovetail guidance of cross table and gear head adjustment
  • rotateable gear head enlarges use of application
  • separate hand wheel for fine feed
  • three spoke hand lever for drilling operation
  • high quality cross table with scale and end stops
  • ideal machine for schools, precision mechanic and DIY userst

included in delivery: drill chuck MT2/B16, speed DRO, drill depth DRO drawbar MT2/M10 toolings

— OR  —

— OR  —

EAN: 9120039904191 MPN: BF20V_230V SKU: L0105 Category:

Description

Technical details

motor data motor power s1 in W 600
voltage  230V
cable length 1,7 m
measurements  payload in kg 55
table size in mm  500 x 180
outreach in mm 160
total dimensions in mm   790 x 590 x 930
technical specification   milling spindle speed in min-1  50-2250
max. face mill diameter in mm 63
max. end mill diameter in mm 16
T-slots in mm 12
head swivel  +/- 90°
travel Z-axis in mm  280
travel Y-axis in mm  165
travel X-axis in mm  280
max. distance spindle-table in mm  370
max. drilling performance steel in mm  Ø 13
milling adapter  MK2/MT2 (M10)
quill travel  50
weight net weight in kg  103
gross weight in kg  126
packaging  packaging height in mm 880
packaging width in mm  560
packaging length in mm  610
general data
EAN code   9120039904191

Additional information

Weight 126 kg
Dimensions 930 × 590 × 790 cm
