SIP Weldmate HG2600A Arc Inverter Welder 05732

SIP Weldmate HG2600A Arc Inverter Welder 05732

549.00 incl. Vat

The SIP HG2600A ARC/TIG Inverter is equipped with a Voltage Reduction Device (VRD), Lift-TIG starting function, anti-stick circuitry, and dinse sockets. Accessories supplied.

— OR  —

— OR  —

EAN: 5012713057320 MPN: 05732 SKU: W0060 Category:

Description

  • 230v (22A) input supply
  • 30A – 250A ARC output current
  • Super high 250A @ 60% duty cycle
  • 1.5 – 10.5mm weld thickness range
  • 1.6 – 5mm max. electrode diameter
  • ARC force for precise weld pool control
  • Switchable Voltage Reduction Device
  • Digital display for weld current setting
  • Lightweight and generator friendly
  • Reliable Lift-TIG starting function
  • Integrated anti-stick circuitry
  • Thermal overload protection
  • 2m Earth / electrode leads

Technical Description:

ITEM NO. 05732
Input Supply 230v (22A)
Output Current 30A – 250A
Duty Cycle 250A @ 60%
Electrode Size ∅ 1.6mm – 5mm
Welding Thickness 1.5mm – 10.5mm
Open Circuit Voltage 80v
Power Factor 0.75
Efficiency 85%
Insulation Class H
Protection IP21S
Net Weight 9.80kg
Gross Weight 10.70kg
Packaged Dimensions 375(H) x 470(W) x 235mm(D)

Additional information

Weight 10 kg
Dimensions 24 × 47 × 38 cm
Brand

SIP Industrial
